📌 Introduction

A JK flip-flop is a refinement of the SR flip-flop that eliminates the invalid state.
It has two inputs, J and K, and one output Q.
Depending on the input combination, it can hold, set, reset, or toggle its output.

Truth Table

J K Q(next) Description
0 0 Q(old) Hold (no change)
0 1 0 Reset
1 0 1 Set
1 1 ~Q(old) Toggle

🧑‍💻 Code Example

module top_module (
    input clk,
    input j,
    input k,
    output reg Q);

	initial Q = 1'b0;
    always @(posedge clk) begin
        if (j & k)
            Q <= ~Q;
        else if (j)
            Q <= 1'b1;
        else if (k)
            Q <= 1'b0;
        // else: hold current value
    end
endmodule
